1. Structural principle of stainless steel glass rotor flowmeter
The structural principle of stainless steel glass rotor flowmeter is as follows
1. Structural composition: The main body is composed of a vertically installed conical glass tube with a small lower end and a large upper end. Float: It can move up and down inside the conical glass tube, used to indicate fluid flow rate. Working principle: Pressure difference generation: When the fluid passes through the conical glass tube from bottom to top, a pressure difference will be generated between the upper and lower parts of the float. Float rising: Under the action of this pressure difference, the float will rise until the rising force, buoyancy, and viscous lift of the float reach equilibrium with the gravity of the float itself. Stable position: When the above force reaches equilibrium, the float will be in a stable position. Flow measurement: There is a certain proportional relationship between the fluid flow rate passing through the flowmeter and the height of the float rising. Therefore, the position height of the float can be used as a measure of flow rate. The relationship between flow rate and float position: When the fluid flow rate increases, the float will rise to maintain pressure balance. When the fluid flow rate decreases, the float will descend. Application: Stainless steel glass rotor flowmeter has a compact structure, easy maintenance, and is suitable for measuring various fluid media, including water, gas, etc. Due to its high measurement accuracy and good stability, it is widely used in industrial production, scientific research, environmental monitoring and other fields.
2. Will there be gas leakage when the glass tube of
If the glass tube of the glass rotor flowmeter cracks, it will cause gas leakage.
. Because the working principle of a glass rotor flowmeter is to calculate the flow rate of gas by measuring the volume of gas passing through a section of glass tube. When the glass tube cracks, gas will leak out from the crack, affecting the accuracy and stability of the flowmeter. In addition, if the leaked gas is hazardous or flammable, it can pose a threat to human health and safety. Therefore, when using a glass skin bright rotor flow state holding measuring instrument, attention should be paid to its maintenance and upkeep to avoid the occurrence of glass tube cracking. Meanwhile, during use, attention should also be paid to observing the condition of the glass tube. If cracks or other damages are found, they should be replaced or repaired in a timely manner.
