1. Calibration Regulations for Flowmeters

The calibration of different types of flowmeters must strictly match the corresponding national/international metrological standards and regulations. The specific calibration requirements are summarized below according to common categories Orifice flow meters must comply with JJF 2033-2023 "Orifice Flow Meter Calibration Specification", which covers the entire calibration process of measurement principles, measurement requirements, environmental conditions, main technical parameters, etc., and is applicable to the calibration of all types of orifice flow meters.

2. Electromagnetic flow meters - Conventional electromagnetic flow meters installed in closed pipelines (excluding flow meters for measuring blood, liquid metal, iron ore slurry, open channel flow, as well as plug-in electromagnetic flow meters and electromagnetic water meters) must undergo type evaluation, initial calibration, subsequent calibration, and in-service inspection in accordance with JJG 1033-2007 "Electromagnetic Flow Meter Calibration Regulations". -On site installation of closed pipeline electromagnetic flowmeter online calibration, applicable to JJF 2216-2025 "Electromagnetic flowmeter online calibration specification"; Online calibration of water metering flow meters can also refer to this specification. 3. Vortex flow meters - Standard compliance: Core standards include the International Electrotechnical Commission IEC 60534 series, GB/T 32201-201, JB/T 924, and JJG 198 calibration regulations. -Precision control: Adopting dual standard management of boundary flow points and three section error band control, the repeatability index follows the 1/3 rule; High level instruments need to hav

e dynamic compensation functions such as real-time Reynolds number compensation. -Fluid calibration: Liquid measurement adopts static volume method, weighing method and sets calibration points; Gas traceability adopts the sonic nozzle method, bell jar device, and matching algorithm. -Full condition verification: including core performance verification (instrument coefficient fitting, linearity, repeatability testing) and environmental adaptability verification (temperature cycling, pressure impact testing, and loss testing). -Calibration cycle: Using a risk-based RBI strategy, the calibration cycle is determined based on instrument grade, medium corrosion coefficient, vibration intensity, etc. Intelligent instruments can apply for cycle extension certification

4. Oil flow meter - Calibration standard: Following the ISO/IEC 17025 measurement system, equipment traceability, environmental control, and method validation must be completed; Conduct static flow verification in an environment of 20 ℃± 2 ℃ according to API MPMS 3.2.4 standard, using NIST certified standard flow sources; The classification of accuracy levels refers to GB/T 26260-2010. -Inspection requirements: A third-party testing institution with both CMA and CNAS qualifications must be selected, and the standardized process of pre inspection and submission of equipment information must be followed. -Error control: It is necessary to consider the impact of environmental factors such as temperature and humidity, as well as operating standards. It is recommended to use a dual person review system. -Regulatory requirements: Chinas "Metrology Law" stipulates that oil flow meters for trade settlement must be mandatorily calibrated every 6 months; The European U
