Emerson Coriolis Flow Meter Calibration Procedure: Step-by-Step Field Zeroing Guide
Quick Answer: Field zeroing on an Emerson Coriolis flow meter corrects the sensor offset when the meter is full of process fluid at zero flow. You do this during commissioning, after a tube replacement, or when a zero drift fault appears. For Silver Instruments Coriolis meters the same field zero routine runs through the local display or HART handheld in about 5 minutes.
This guide covers the field zeroing procedure for Emerson Coriolis flow meters including Micro Motion sensors and transmitters. We have seen many customer sites where a poor zero check causes a stable offset at no flow. Because the zero point is the reference for all mass flow readings, a small mistake here can shift every batch by a fixed amount. A paint manufacturer in Southeast Asia saw a 12 kg/h offset on a DN25 line after a pump change. The error only appeared when the line was full but blocked.
When to Perform a Field Zero on an Emerson Coriolis Flow Meter
Run a field zero only when the meter is full of process fluid and flow is completely stopped. Common triggers are first commissioning, a new sensor or transmitter, after changing the process fluid temperature by more than 20 °C, after a physical impact, or when the transmitter shows a zero drift alarm. Most engineers skip this part after winter shutdown. In practice that is when we see the largest offsets.
The meter must see real process conditions. Do not zero with air or water if the line normally runs edible oil at 90 °C. The zero offset changes with density, viscosity, and temperature. For a 40 cP corn syrup line, zeroing with water created a 0.08 percent reading shift on a DN50 meter.
Tools and Safety Checks Before Zeroing
You need the HART handheld, the ProLink software, or the local display keys. Confirm the transmitter firmware version. For Micro Motion 2700 transmitters the display reads the zero time and zero value. For ATEX Zone 1 areas use a suitable HART communicator and follow site permit rules.
Close the upstream valve. Close the downstream valve. Release pressure if required by site procedure. Check for any bypass flow. A small leak through a seat valve can add a false 0.3 kg/h signal on a DN15 line. Let the system settle until temperature and pressure are stable. Usually 5 to 10 minutes is enough.
Step-by-Step Field Zeroing Procedure for Emerson Coriolis Meters
Step 1. Fill the meter with process fluid. Confirm zero flow by a mechanical stop or block valve. Do not rely on a pump stopped signal alone. We have seen a check valve leak cause a 1.2 kg/h drift on a DN20 methanol line.
Step 2. Open the zero calibration menu. On a Micro Motion 2700 transmitter press the service menu and select Zero Calibration. On ProLink click Calibration then Zero Calibration. The transmitter will ask you to verify zero flow. Answer yes.
Step 3. Wait for the zero routine. The display shows a countdown or a progress bar. A typical CMF200 sensor takes 20 to 40 seconds to complete the zero. The 2700 transmitter writes the new zero value to memory.
Step 4. Check the zero value after the routine. For a DN15 meter with 10 cP fluid the zero value should be within a few microseconds. The exact limit depends on the sensor model. A shift from 2.1 µs to 8.5 µs on a DN25 line often means the meter was not full or
Step 5. Return the meter to normal operation. Open the downstream valve then the upstream valve. Watch the live mass flow for 60 seconds. It should read 0.0 kg/h plus or minus the zero stability spec.
Step 6. Record the zero value, date, operator name, process fluid, temperature, and pressure. This record helps troubleshoot drift later. A food plant in Vietnam cut downtime by 40 percent after they started keeping a zero logbook.
Common Mistakes During Field Zeroing
Here is the thing. A field zero is not the same as a factory calibration. It only removes the sensor offset at no flow. It does not fix a bad tube, a wrong K factor, or a bad density calibration. If the zero value jumps between runs, check for air pockets, pipe stress, pump vibration, or a loose sensor mounting.
Another mistake is zeroing with the line under static pressure but with a gas pocket at the top. On horizontal installations the sensor must remain full. A 3 percent gas pocket on a DN40 line can cause a zero offset that looks like a real flow of 0.5 kg/h.
Silver Instruments Support for Coriolis Zeroing and Calibration
Silver Automation Instruments supplies Coriolis mass flow meters from DN15 to DN300 for oil, gas, chemical, food, and water applications. We also supply electromagnetic flow meters, ultrasonic flow meters, oval gear flow meters, thermal mass flow meters, pressure transmitters, and paperless recorders. We help customers set up field zeroing on Emerson and other Coriolis meters. Our engineers can check your zero procedure by remote call or on site. Send us your pressure in bar, temperature in °C, pipe size in DN, and flow range. We will send a calibration checklist or a quote for a replacement meter.
You can reach us at Tel: +86-25-68650347, WhatsApp: +86-25-52155837, or WeChat: +86 15365082610. Our website is flow-meter.com.au
FAQ
Q1: How often should I run a field zero on an Emerson Coriolis flow meter?
Answer: Check zero at commissioning and during every scheduled shutdown. If the process fluid changes or the meter is moved, run a new zero. Most plants in the food and chemical sectors do this every 3 to 6 months.
Q2: Can I zero an Emerson Coriolis meter with water if the process fluid is oil?
Answer: This is not recommended. The zero offset depends on density, viscosity, temperature, and mounting stress. Zero with the normal process fluid at operating temperature when possible.
Q3: Why does my Emerson meter show a steady flow when the pump is off?
Answer: Check the zero point first. If the zero value is stable but wrong, run the field zero routine with a full blocked line. Also check for vibration from nearby pumps and check valve leakage.
Q4: Does Silver Automation Instruments sell a direct replacement for an Emerson Coriolis meter?
Answer: Yes. We offer Coriolis mass flow meters from DN15 to DN300 with 4-20 mA HART, pulse, and RS485 outputs. Many customers in the oil and gas and water sectors use our meters as replacements.
Q5: What is a normal zero value for a Micro Motion CMF200 sensor?
Answer: The normal zero value depends on the sensor size and process conditions. For a DN25 CMF200 with water at 25 °C the zero value is often below 10 µs. If the value jumps by more than a few µs between zero runs, inspect the mounting and fill condition.
