Battery powered flowmeter

『Battery powered flowmeter』Related information(clamp on meter|electromagnetic meter|venturi meterrotameter|orifice meter|ultrasonic flow meter|mass flow meter|coriolis mass flow meter|coriolis flow meter|magnetic flow meter|magmeter flow meter|magflow flow meter|mag meter flow meter|electromagnetic flow meter|vortex flow meter|turbine flow meter|thermal mass flow meter|thermal flow meter|rotameter flow meter)

1. Pipeline flowmeter

2. Selection of battery powered turbine flowmeter

When selecting a battery powered turbine flowmeter, the first consideration is the measurement requirements. The LWGY series offers multiple specifications to accommodate different applications. For example, for DN40 diesel pipelines, if flange connection is required, the LWGY-40 (FL) model can be selected. Its characteristic is explosion-proof type (Exm Ⅱ CT6 or Exd Ⅱ BT6), ensuring safe operation of the Weina in high-pressure environments. For on-site display and remote transmission of current signals, the LWGY series offers a C-type, which means you will receive battery powered on-site display and 4-20mA two-wire current output function. The accuracy level is 0.5, ensuring the accuracy of the measurement results. The accuracy level option for LWGY is 05. Considering the material of the pipeline, choosing S304 stainless steel for turbine components is the correct choice for 304 stainless steel. In terms of pressure rating, due to the need to withstand a pressure of 16MPa, the H (x) high-pressure version should be selected. In terms of measurement range, diesel belongs to the standard range, so the S standard turbine is selected. In summary, based on the above conditions, you should choose the turbine flowmeter model LWGY-40 (FL)/C/05/S/S/E/H16.

3. Product features of battery powered turbine flowmeter

The battery powered turbine flowmeter has various significant characteristics, ensuring high-precision measurement and wide application.

. Firstly, its accuracy is extremely high, with standard models reaching ± 1% R and even high-precision models reaching an astonishing ± 0.2% R, which is particularly crucial in tr
Battery powered flowmeter
ade settlement. Excellent repeatability, with short-term repeatability between 0.05% and 0.2%. Through regular calibration or online calibration, accuracy can be further improved. In addition, the flowmeter outputs a pulse frequency signal, which is suitable for total measurement and connection with computers. It has no zero drift and strong anti-interference ability. The signal resolution is also very strong, and the frequency range can reach 3-4kHz. In terms of design, the range of the flowmeter is very wide, with medium and large diameters up to 1:20, and small diameters also supporting a 1:10 ratio, making it suitable for various pipeline sizes. The structure is compact and lightweight, easy to install and maintain, and the spring pants have a large flow capacity. They can also handle high-pressure measurement environments without the need for additional openings on the instrument body. According to the different needs of users, the Orange Lift flowmeter also provides various specialized sensors, such as low-temperature, bidirectional, downhole, and sand mixing specialized, to meet the requirements of special working environments. In addition, it can be made into an insertion type, suitable for large-diameter measurement, with low pressure loss, economical price, easy to continuously flow out, and easy installation and maintenance. In terms of technical performance, the flowmeter provides a detailed specification sheet, including instrument diameter, connection method, accuracy level, range ratio, material, pressure resistance level, and other information. For example, the flow range of 40mm caliber is 0.04~0.25m/h, and the maximum pressure resistance can reach 12MPa, which can meet the needs of different occasions.
