1. Top 10 brands of thermal gas mass flow meters

2. What are the well-known brands of steam flow meters

3. What are the commonly used flow meters and their characteristics?

4. What are the potential safety hazards of the mass flow meter quantitative loading system when it leaves the factory?

The potential safety hazards of the mass flow meter quantitative loading system mainly focus on four dimensions: hardware assembly, software logic, safety protection matching, and compliance verification. If not properly investigated, it will cause safety accidents such as material leakage, inaccurate measurement, and flammable medium explosion..

1. Hardware assembly hazards (1) Sealing system adaptation deviation 1 The selection of sealing components such as O-rings and corrugated pipes for the loading interface does not match the characteristics of the medium and working pressure. For example, low-temperature LNG loading uses room temperature nitrile rubber seals, which can cause leakage due to seal brittleness at low temperatures; 2. The installation torque of the sealing element was not controlled according to the process requirements. If the torque is too small, the seal is not tight, and if it is too large, the sealing lip is squeezed and damaged, resulting in medium leakage after long-term operation. （2） The installation stress of the sensor has not been eliminated The mass flow meter is hard connected to the front and rear pipelines without reserved allowance for thermal expansion and contraction, or forcibly aligned during installation, resulting in additional stress on the sensor core, causing zero drift, decreased measurement accuracy, and in severe cases, damaging the intern

Zibo Low Temperature Mass Flow Meter Manufacturer

al vibrating string components; 2. The connection between the crane tube and the flowmeter did not use a flexible joint, and the vibration of the pipeline was transmitted to the flowmeter, exacerbating the wear of the movement. （3） Emergency execution agency linkage failure 1 The emergency shut-off valve and pneumatic crane locking mechanism of the loading system were only tested for individual power on without factory linkage verification. During actual loading, if the pipeline ruptures or the vehicle shifts, the shut-off valve cannot be activated in a timely manner; 2. The rated pulling force of the disconnect valve is not calibrated according to the working conditions of the loading area. If the pulling force is too high, it cannot break the pipeline in a timely manner when the vehicle moves, or if it is too low, it may trigger the disconnection incorrectly during normal loading and unloading. （4） Lack of anti-static grounding configuration 1 The grounding terminals of flow meters, crane tubes, and loading arms are not configured with jumper wires in accordance with the requirements of GB 50058-2014 "Code for Design of Electric Power Installations in Explosive Hazardous Environments", and static electricity cannot be effectively conducted, causing flash explosions when combustible media leaks.

II. Software Logic Hazards (1) Quantitative Control Logic Vulnerabilities 1 The threshold settings for excessive alarm and overflow protection did not match the rated capacity of the tanker truck, and a safety margin of 1% -2% was not reserved, resulting in excessive overflow during loading; 2. Communication interruption protection logic is missing. After the communication between the flow meter and the central control ro

Zibo Low Temperature Mass Flow Meter Manufacturer

1. Top 10 brands of thermal gas mass flow meters

2. What are the well-known brands of steam flow meters

3. What are the commonly used flow meters and their characteristics?

4. What are the potential safety hazards of the mass flow meter quantitative loading system when it leaves the factory?
