1. Working principle and main characteristics of gas flowmeter

Working principle of gas flowmeter: Gas flowmeter is a new type of flow measurement instrument made based on the principle of "Karman vortex". When a stable fluid flows through a straight pipeline of a certain length, it will collide with a nonlinear cylinder immersed in the fluid, thereby generating a vortex downstream of the fluid, known as the Karman vortex. The occurrence pattern of vortices is stable and reliable within a certain Reynolds number (Re) range. The frequency F of vortex occurrence is determined by the formula F=(St * V)/d, where V is the flow velocity and d is the width of the upstream face of the cylinder. By measuring the frequency of the vortex, the flow velocity and flow rate of the fluid can be accurately calculated. The main characteristics of gas flow meters are: simple and sturdy structure: gas flow meters have no movable parts, simple and sturdy structure, therefore they have extremely high reliability and long-term stable operation. Easy installation and maintenance: Due to its simple structure, the installation process of gas flow meters is relatively easy, and maintenance is also very convenient, reducing the cost of use. Stable performance and long lifespan: The detection sensor does not directly contact the measured medium, avoiding damage to the sensor caused by changes in medium properties, thereby ensuring stable performance and a longer service life. High precision output: The gas flowmeter outputs a pulse signal proportional to the flow rate, without zero drift, thus having high measurement accuracy. Wide measurement range: The range ratio of gas flow meters can reach 1:10, with a wide measurement range and a wi

de bandwidth, suitable for measuring different flow ranges of Xiaotai Lu. Small pressure loss and good energy-saving effect: During the measurement process, the pressure loss generated by the gas flowmeter is relatively small, which helps to reduce operating costs and achieve energy-saving effects. Stable output signal frequency: Within a certain Reynolds number range, the output signal frequency of a gas flowmeter is not affected by the physical properties and composition changes of the fluid, and the instrument coefficient is only related to the shape and size of the vortex generator. Therefore, there is no need for compensation when measuring fluid volume flow rate, and there is generally no need to recalibrate instrument coefficients after replacing accessories. Widely applicable: Gas flow meters have a wide range of applications, not only measuring the flow rate of steam and liquids, but also measuring the flow rate of gases, meeting the measurement needs of different industries and media. (Note: The above image is a schematic diagram of the working principle of a gas flowmeter, showing the process of fluid flow through a nonlinear cylinder to generate vortices.) In summary, gas flowmeters have been widely used and recognized in industries such as petroleum, chemical, metallurgy, and papermaking due to their unique working principle and many advantages.

2. Reynolds number range of turbine flowmeter

The Reynolds number range of turbine flowmeter is closely related to the nominal diameter, and the normal operating Reynolds number range is usually 20000-700000.

. 1. During stable measurement, the Reynolds number range of a turbine flowmeter in normal operation is generally 20000-700000. When it is bel
